Centrifugal Blowers and Models
High-Speed Centrifugal Blowers for Various Applications
Comprehensive line of Sonic Air Systems’ industrial centrifugal blowers and models.
Sonic Air Systems specializes in manufacturing industrial-grade centrifugal blowers, catering to a wide range of air, gas, and air knife applications. Our compact belt-driven blowers, ranging from 3 to 50 horsepower, deliver exceptional performance with airflow capacities from 100 to 3,500 CFM and vacuum ratings up to 8" Hg. Designed for 24/7 operation, our blowers feature sealed, grease-packed bearings and PTFE shaft seals for reliable performance. Whether it's drying, air handling, heating, cooling, or blow-off applications, our energy-efficient blowers are trusted by industries worldwide.
Sonic Air Systems specializes in manufacturing industrial-grade centrifugal blowers, catering to a wide range of air, gas, and air knife applications. Our compact belt-driven blowers, ranging from 3 to 50 horsepower, deliver exceptional performance with airflow capacities from 100 to 3,500 CFM and vacuum ratings up to 8" Hg. Designed for 24/7 operation, our blowers feature sealed, grease-packed bearings and PTFE shaft seals for reliable performance. Whether it's drying, air handling, heating, cooling, or blow-off applications, our energy-efficient blowers are trusted by industries worldwide.
Centrifugal Blower Models:
Model
Type
Details
Sonic 70
Single Stage
Sonic 70
Sonic 70
Centrifugal Blower
Performance range: Flow: 50 to 700 SCFM (85 to 1,189 m³/hr)
Pressure: 0.5 to 3.5 PSIG (3.4 to 24.1 kPa) Vacuum: 1.0 to 6.6 "Hg (34 to 224 mbar)
Standard Features:
- Auto belt tensioner
- Multiple mounting configurations
- Small size and footprint
- Adaptable to IEC and NEMA motors
- Lightweight aluminum construction
- Hard anodize and special materials
Options:
- High inlet temperature (400°F / 205°C)
- Thermocouple for PLC monitoring
- Wash down, explosion proof, and chemical duty motors
- Hydraulic, pneumatic, and PTO motors
- Welded inlet and outlet flanges
Specification Sheets
.svg)
Sonic 85
Single Stage
Sonic 85
Sonic 85
Centrifugal Blower
Performance range: Flow: 100 to 850 SCFM (170 to 1,445 m³/hr)
Pressure: 0.5 to 3.75 PSIG (3.4 to 25.8 mbar) Vacuum: 1.0 to 7.0 "Hg (34 to 237 mbar)
Standard Features:
- Auto belt tensioner
- Multiple mounting configurations
- Small size and footprint
- Adaptable to IEC and NEMA motors
- Lightweight aluminum construction
- Hard anodize and special materials
Options:
- High inlet temperature (400°F / 205°C)
- Thermocouple for PLC monitoring
- Wash down, explosion proof, and chemical duty motors
- Hydraulic, pneumatic, and PTO motors
- Welded inlet and outlet flanges
Specification Sheets
Sonic 100
Single Stage
Sonic 100
Sonic 100
Centrifugal Blower
Performance range: Flow: 100 to 1,000 SCFM (170 to 1,700 m³/hr)
Pressure: 0.5 to 3.5 PSIG (3.4 to 24.1 kPa) Vacuum: 1.0 to 6.6 "Hg (34 to 224 mbar)
Standard Features:
- Auto belt tensioner
- Multiple mounting configurations
- Small size and footprint
- Adaptable to IEC and NEMA motors
- Lightweight aluminum construction
- Hard anodize and special materials
Options:
- High inlet temperature (400°F / 205°C)
- Thermocouple for PLC monitoring
- Wash down, explosion proof, and chemical duty motors
- Hydraulic, pneumatic, and PTO motors
- Welded inlet and outlet flanges
Specification Sheets
Sonic 150
Single Stage
Sonic 150
Sonic 150
Centrifugal Blower
Flow: 100 to 1,200 SCFM (170 to 2,039m³/hr)
Pressure: 0.5 to 4.2 PSIG (3.4 to 28.9 kPa) Vacuum: 1.0 to 8.1 "Hg (34 to 274 mbar)
Standard Features:
- Auto belt tensioner
- Multiple mounting configurations
- Small size and footprint
- Adaptable to IEC and NEMA motors
- Lightweight aluminum construction
- Hard anodize and special materials
Options:
- High inlet temperature (400°F / 205°C)
- Thermocouple for PLC monitoring
- Wash down, explosion proof, and chemical duty motors
- Hydraulic, pneumatic, and PTO motors
- Welded inlet and outlet flanges
Specification Sheets
Sonic 200
Dual Parallel
Sonic 200
Sonic 200
Centrifugal Blower
Flow: 200 to 2,000 SCFM (340 to 3,398 m³/hr)
Pressure: 0.5 to 3.5 PSIG (3.4 to 24.1 kPa) Vacuum: 1.0 to 6.6 "Hg (34 to 224 mbar)
Standard Features:
- Auto belt tensioner
- Multiple mounting configurations
- Small size and footprint
- Adaptable to IEC and NEMA motors
- Lightweight aluminum construction
- Hard anodize and special materials
Options:
- High inlet temperature (400°F / 205°C)
- Thermocouple for PLC monitoring
- Wash down, explosion proof, and chemical duty motors
- Hydraulic, pneumatic, and PTO motors
- Welded inlet and outlet flanges
Specification Sheets
Sonic 300
Dual Parallel
Sonic 300
Sonic 300
Centrifugal Blower
Flow: 200 to 2,400 SCFM (340 to 4,078 m³/hr)
Pressure: 0.5 to 4.2 PSIG (3.4 to 28.9 kPa) Vacuum: 1.0 to 8.1 "Hg (34 to 274 mbar)
Standard Features:
- Auto belt tensioner
- Multiple mounting configurations
- Small size and footprint
- Adaptable to IEC and NEMA motors
- Lightweight aluminum construction
- Hard anodize and special materials
Options:
- High inlet temperature (400°F / 205°C)
- Thermocouple for PLC monitoring
- Wash down, explosion proof, and chemical duty motors
- Hydraulic, pneumatic, and PTO motors
- Welded inlet and outlet flanges
Specification Sheets
Sonic 350
Two Stage
Sonic 350
Sonic 350
Centrifugal Blower
Flow: 350 to 3,500 SCFM (595 to 5,946 m³/hr)
Pressure: 0.5 to 3.5 PSIG (3.4 to 24.1 kPa) Vacuum: 1.0 to 6.6 "Hg (34 to 224 mbar)
Standard Features:
- Multiple mounting configurations
- Small size and footprint
- Adaptable to IEC and NEMA motors
Specification Sheets
